2| Product description
 Liquidsubcooler,expansionvalve,solenoidvalve,lterdrierandasightglassenclosed
separately,forindividual,externalmounting(Fig.3).
 Liquidsubcooler,expansionvalve,solenoidvalve,lterdrierandasightglassmounted
directlytothecompressor,pipedandinsulated(Fig.4).
2.3 Short description optional version, mounted
Dimension and connection values can be found in Chapter 10
Sight glass
2.2 Short description optional version, enclosed
Fig. 3
Liquid
subcooler
Filter drierSolenoid valve
Fig. 4
Expansion
valve
