PISTON AND CONNECTING ROD FIG. RC9-4
1
1.1
1.2
1.3
1.4
Piston assy S110x40x110FA85
Gudgeon pin 28x40x90RC9
Piston
Set of piston rings 110KA85
Snap ring 40
24.06.000
24.20.300
*
09.74.114
11.04.040
1
1
1
1
2
2a
2.1a
2.2a
Con rod assy S65x210KA85
Bearing bush 40x46x38
Connecting rod E70x210KA85
24.06.500
11.46.440
*
1
1
1
in single-stage compr. and in LP-
cyl. of two-stage compressors
2b
2.1b
2.2b
Con rod assy 65x210RC9 HD
Needle bearing RNA 69/32
Connecting rod 70x210RC9 HD
24.21.550
11.63.452
*
1
1
1
in HP-cyl. of two-stage compr. only
2.3
2.4
2.5
2.6
Bearing shell 65x30
Con rod bolt MF12
Locking plate M12
Hex. nut MF12
11.44.365
01.11.601
11.19.600
01.47.605
1
2
2
2
CYLINDER AND VALVE LIFTING MECHANISM FIG. RC9-5
1
2
3a
3b
3c
Cylinder liner 110FA85
Lifting bush FA85
Oilit sealing ring 150x160x1
Oilit sealing ring 150x161.5x1.25
Oilit sealing ring 150x160x1.5
23.06.000
27.06.600
09.02.150
09.01.150
09.03.150
1
1
1
1
1
1 mm thick
1.25 mm thick
1.5 mm thick
4
4.1
4.2
4.3
4.4
4.5
4.6
4.7
4.8
4.9a
4.10a
4.11a
4.9b
4.10b
4.11b
Valve-lifting mechanism
Plug G33
O-ring 3x33
Piston housing FA55M
Spring 3.2x22x9x80
Control piston
Lever FA55
O-ring 3.53x23.4
O-ring 3.5x36
Cover 060G13
Hex. head bolt M10x25
Nipple coupling 6G13
Cover KA60x85A
Socket head screw M10x20
Nipple coupling 6G10
*
01.36.336
09.52.300
27.10.501
11.31.322
27.10.520
27.10.550
09.52.360
09.52.348
05.38.013
01.10.525
03.38.136
27.14.605
01.04.520
03.38.106
1
1
1
1
1
1
1
1
1
1
2
1
1
2
1
with O-ring groove only
1
)
for 2- and 4-cyl. compressors
for 6-cyl. compressors only
5
6
7
8
Oilit gasket 20x58x1.5
O-ring
Stud M8x22
Washer M8
Hex. nut M8
09.07.020
09.52.367
01.51.422
11.13.401
01.15.410
1
1
4
4
1
for housing (4.3) with gasket recess
for housing (4.3) with O-ring groove1
1
) This piston housing (Ref. Nr. 27.10.501) always includes an O-ring with Ref. Nr. 09.52.367.
Refrigeration Division
Grasso
STANDARD ILLUSTRATED PARTS LIST RC9
C6 Refrigeration Compressors Series RC9 v003.99.06.en
