Item Description Ref. No. Qty Remarks
OIL RETURN LINES FIG. RC9-10
1a
1b
1c
Oil return line G21x360
Oil return line G21x400
Oil return line G21x440
44.05.924
44.05.945
44.05.964
1
1
1
2-cyl. compressor
3- and 4-cyl. compressor
6-cyl. compressor
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
1.9
1.10
Valve housing H9K
Alu sealing ring 21.5x27x1
Steel ball W16
Spring 1.25x14x9x3.55
Thrust bolt G21x60S
O-ring 1.78x8.73
Nipple G21CxG21
Alu sealing ring 10x18x1
Cap nut GK21R
Weldable coupling 6x11
*
09.12.022
11.19.010
11.31.134
01.35.218
09.52.184
03.04.921
09.12.010
01.17.021
03.35.006
—
1
1
1
1
1
1
1
1
1
2
3
Coupling 12G21
Weldable coupling 6x11
03.38.212
03.46.028
1
1
SUCTION GAS STRAINER FIG. RC9-11
1
2a
3a
4a
5a
Suction strainer housing
Hex. haed bolt M16x60
Blind flange 89B
Oilit ring 98x112x1.5
Hex. nut M16
*
01.10.860
05.14.089
09.03.098
01.15.810
1
8
1
2
8
RC29, RC49 and RC219
2b
3b
4b
5b
Hex. head bolt M20x70
Blind flange 108B
Oilit ring 117x131x1.5
Hex. nut M20
01.10.170
05.14.108
09.03.117
01.15.110
8
2
2
8
RC69 and RC429
6
8
Weldable coupling 6x11
Flange 89-60
03.35.006
05.02.261
—
1 RC29, RC49 and RC219
9a
9b
Strainer element 360x110
Strainer element 600x110
07.16.360
07.16.600
1
1
2
RC29
RC49 and RC219
RC69 and RC429
Refrigeration Division
Grasso
STANDARD ILLUSTRATED PARTS LIST RC9
C14 Refrigeration Compressors Series RC9 v003.99.06.en
