Item Description Ref. No. Qty Remarks
ELASTIC COUPLING FIG. RC9-16
1a
1.1a
1b
1.1b
1c
1.1c
1d
1.1d
Coupling type 42 (complete)
Coupling element 42
Coupling type 61 (complete)
Coupling element 61
Coupling type 91 (complete)
Coupling element 91
Coupling type 182 (complete)
Coupling element 182
*
19.18.842
*
19.18.861
*
19.18.891
19.18.818
1
1
1
1
1
1
1
1
to facilitate mounting, a steel strip is
clamped around the coupling ele-
ment, which must be removed
before putting the compressor into
operation
2
3
Clamping sleeve
Tire clamp (coupling tool)
Tire clamp (coupling tool)
Tire clamp (coupling tool)
Tire clamp (coupling tool)
*
15.08.232
15.08.244
15.08.280
15.08.376
1
1
1
1
1
for coupling element 42
1
)
for coupling element 61
1
)
for coupling element 91
1
)
for coupling element 182
1
)
4
5
6
7
Hub locking disc M16x82
Locking plate M16xM8
Washer M8
Hex. head bolt M8x30
19.15.882
11.14.848
11.13.401
01.10.430
1
1
1
4
to be supplied with flywheel or
flexible coupling
PARTS FOR CLAMP COUPLINGS FIG. RC9-17
1a
2a
1b
2b
3
4
Clamping sleeve P6
Union nut M12x1.5 (DIN 2353)
Union nut M14x1.5 (DIN 2353)
Clamping sleeve P16
Union nut MF24x1.5 (DIN 2353)
Clamping sleeve S6
Union nut MF12x1.5 (special)
03.34.506
*
*
03.34.516
*
03.34.106
03.51.006
—
—
—
—
—
—
—
to be used on clamp couplings
with reference number:
03.37.106
03.37.176
03.38.131
03.38.136
03.39.136
03.40.006
03.35.006
03.35.016
03.38.212
03.52.006
03.54.076
1
) When ordering this tire clamp always indicate the type number of the elastic coupling.
Refrigeration Division
Grasso
STANDARD ILLUSTRATED PARTS LIST RC9
v003.99.06.en Refrigeration Compressors Series RC9 C21
