STANDARD SETS OF PARTS, SEALS AND TOOLS NO FIGURE
Item Description Ref. No.
Qty for compressor types
RC29 RC219/49 RC429/69
1 Set of special tools
20.20.010 1 1 1
2 Basic set of spare parts
Additional set of spare parts
20.20.021
20.20.031
1
—
1
1
1
2
3 Basic set of gaskets and seals
Additional set of gaskets and seals
09.90.007
09.90.008
1
1
1
2
1
3
COMPRESSOR (LP) SUCTION INTERMEDIATE (HP) DISCHARGE
LP DISCHARGE HP SUCTION
MODEL SIZE PART NO. SIZE PART NO. SIZE PART NO. SIZE PART NO.
RC29
SINGLE- STAGE
98X112X1.5 09.03.098 48X58X1.5 09.03.048
RC49 98X112X1.5 09.03.098 67X81X1.5 09.03.067
RC69 98X112X1.5 09.03.098 84X98X1.5 09.03.084
RC219
TWO- STAGE
98X112X1.5 09.03.098 48X58X1.5 09.03.048 48X58X1.5 09.03.048 48X58X1.5 09.03.048
RC429 84X 98X1.5 09.03.084 48X58X1.5 09.03.048 84X98X1.5 09.03.084 84X98X1.5 09.03.084
FLANGE NO. 1 FLANGE NO. 2 FLANGE NO. 3 FLANGE NO. 4
OILIT SEALING RINGS FOR SUCTION-, INTERMEDIATE- AND DISCHARGE CONNECTIONS (FIG. RC9-18)
Refrigeration Division
Grasso
STANDARD ILLUSTRATED PARTS LIST RC9
C22 Refrigeration Compressors Series RC9 v003.99.06.en
