GEA Grasso RC49 User Manual

Item Description Ref. No. Qty Remarks
OIL FILTERS FIG. RC9-9
1X
1Y
Oil suction filter assy RC9
Oil suction filter assy RC9
07.15.909
07.15.969
1
1
on compr. types RC29, RC49 & RC219
on compr. types RC69 & RC429
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
1.9
1.10
1.11
1.12
1.13
1.14
1.15
1.16
1.17
1.18
1.19
Filter upper housing
Swivel coupling 16G21
Steel precision pipe 16 x2
Weldable nipple G21L
Union nut G21R
Pipe end G21
Alu sealing ring 10x18x1
Union socket G21RxG21L
Stop valve TAH8
Cap nut K21R
Steel precision pipe 16 x2
Nipple coupling 16G21
Plug G21
Alu sealing ring 21x27x2
Set of sealing rings
Gauze filter element (blue marked on top)
Filter cup 25
Spring
Ring nut
*
03.39.216
*
*
*
*
09.12.010
03.29.921
06.07.013
01.17.021
*
03.38.212
01.36.216
09.14.023
09.90.030
07.16.695
*
*
*
1
1
--
1
1
--
2
1
1
1
--
1
2
2
1
1
1
1
1
form one welded piece
2
2.1
2.2
2.3
2.4
2.5
2.6
2.7
2.8
2.9
2.10
2.11
2.12
Oil discharge filter assy RC9
Filter upper housing
Swivel coupling 16G21
Steel precision pipe 16x2
Nipple coupling 16G21
Plug G21
Alu sealing ring 21x27x2
Set of sealing rings
Discharge Paper filter element set
Filter cup 25
Spring
Ring nut
Steel precision pipe 16x2
07.15.809
*
03.39.216
*
03.38.212
01.36.216
09.14.023
09.90.030
20.38.124
*
*
*
*
1
1
1
--
3
2
3
1
1
1
1
1
--
Sealings included
3
4
Alu sealing ring 10x18x1
Alu sealing ring 21x27x2
09.12.010
09.14.023
1
3
Refrigeration Division
Grasso
STANDARD ILLUSTRATED PARTS LIST RC9
v003.99.06.en Refrigeration Compressors Series RC9 C13
