9| Dimensions and connections
SV
DV
Suction line
Discharge line
see technical data, Chapter 8
A
*
Connection suction side, not lockable
1
/
8
“ NPTF
A1
Connection suction side, lockable
7
/
16
“ UNF
B
Connection discharge side, not lockable
1
/
8
“ NPTF
B1
Connection discharge side, lockable
7
/
16
“ UNF
C
Connectoin oil pressure switch OIL
7
/
16
“ UNF
D
Connection oil pressure switch LP
7
/
16
“ UNF
D1
Connection oil return from oil separator
1
/
4
“ NPTF
E
Connection oil pressure gauge
1
/
8
“ NPTF
F
Oil drain
M22 x 1,5
H
Oil charge plug
M22 x 1,5
J1
Oil
sump heater (accessories)
M22 x 1,5
K
Sight glass
-
L1
Thermal protection thermostat
1
/
8
“ NPTF
O
Connection oil level regulator
3 x M6
P
Connection oil differential pressure sensor
M20 x 1,5
ÖV
Connection oil service valve
1
/
4
“ NPTF
Q
Connection oil temperature sensor
1
/
8
“ NPTF
SI1
Decompression valve HP
1
/
8
“ NPTF
SI2
Decompression valve LP
1
/
8
“ NPTF
* = only with additional adapter possible
