6
D
GB
F
E
96020-09.2013-DGbFEI
Name plate
Fig. 1
Fig. 2
Oil sight glass
Valve plate
Cylinder cover
Discharge
shut-off valve
Oil pump
Terminal box
Suction
shut-off valve
Drive section
Motor section
Dimension and connection values can be found in Chapter 9
Transport eyelet
2| Product description
• Semi-hermeticfour-cylinderreciprocatingcompressorwithsuction-gascooleddrivemotor.
• Flange-mounted drive motor on the compressor case.
• The stream of refrigerant sucked out of the evaporator flows over the motor and cools it
intensively. In this way, the motor can be kept at a relatively low temperature level, particularly
under high loads
2.1 Short description
