2| Product description
2.2 Name plate (example)
2.3 Typekey (example)
¹
)
HG - Hermetic Gas-Cooled (suction gas-cooled) for deep-freezing
²
)
X - Ester oil charge
Fig. 3
/
HG 4
310-
4
CO
2
X
CO
2
Version
Number of poles
Swept volume
Size
Oil charge ²
)
Series ¹
)
1 Typedesignation 6 Voltage,circuit,frequency
2 Machine number 7 Nominal rotation speed
3 maximum operating current 8 Displacement
4 Startingcurrent(rotorblocked) 9 Voltage,circuit,frequency
Y: Part winding 1 10 Nominal rotation speed
YY: Part windings 1 and 2 11 Displacement
5 ND (LP):
max. admissible operating
12 Oiltypelledatthefactory
pressur
e (g) Low pressure side 13 Terminal box protection type
HD (HP):
max. admissible operating
Electrical accessories can change
pressur
e (g) High pressure side the IP protection class!
Observe the limits of application
diagrams!
50 Hz
}
60 Hz
}
