Suctionline
Dischargeline
seetechnicaldata,Chapter8
A
Connectionsuctionside,notlockable
1
/
8
“ NPTF
A1
Connectionsuctionside,lockable
7
/
16
“ UNF
A2
Connectionsuctionside,notlockable
1
/
4
“ NPTF
B
Connectiondischargeside,notlockable
1
/
8
“ NPTF
B1
Connectiondischargeside,lockable
7
/
16
“ UNF
C
ConnectoinoilpressureswitchOIL
7
/
16
“ UNF
D
ConnectionoilpressureswitchLP
7
/
16
“ UNF
D1
Connectionoilreturnfromoilseparator
1
/
4
“ NPTF
E
Connectionoilpressuregauge
7
/
16
“ UNF
F
Oildrain M22x1,5
H
Oilchargeplug M22x1,5
J1
Oil sumpheater(accessories)
M22x1,5
K
Sightglass -
L
Connectionthermalprotectionthermostat
1
/
8
“ NPTF
O
Connectionoillevelregulator 3xM6
ÖV
Connectionoilservicevalve
1
/
4
“ NPTF
P
Connectionoildifferentialpressuresensor M22x1,5
Q
Connectionoiltemperaturesensor
1
/
8
“ NPTF
9| Dimensions and connections
