GEA HGX7 R134a User Manual

D
GB
F
E
7
96182-09.2013-DGbFEI
SE 55
AS09529A001
81,0 A
291 A 429 A
GEA Bock GmbH
72636 Frickenhausen, Germany
HGX7/2110-4 R134a
1 Typedesignation 6 Voltage,circuit,frequency
2 Machinenumber 7 Nominalrotationspeed
3 maximumoperatingcurrent 8 Displacement
4 Startingcurrent(rotorblocked) 9 Voltage,circuit,frequency
Δ:Partwinding1 10 Nominalrotationspeed
 YYY:Partwindings1and2 11 Displacement
5 ND(LP): max.admissibleoperating  12 Oiltypelledatthefactory
pressur e (g)Lowpressureside 13 Terminalboxprotectiontype
 HD(HP): max.admissibleoperating Electrical accessories can change
pressur e(g)Highpressureside  the IP protection class!
Observe the limits of application
diagrams!
50 Hz
}
60 Hz
}
2| Product description
/
HG 7
2110-
4
X
2.3 Typekey (example)
1)
HG-Hermetic-Gas-cooled(suctiongascooled)
2)
X - Esteroilfilling
R134a
Motorvariant
Numberofpoles
Sweptvolume
Size
Esteroillling²
)
Series¹
)
Fig.2
2.2 Name plate (example)

GEA HGX7 R134a Specifications
