11 ∙ Betriebsvorschriften / Operating Instructions
10. Ersatzteilliste
10. Spare Parts List
DN1
Spindel
Stem
Flachdichtring K (Aluminium)
Flat Sealing Ring K (Aluminum)
Flachdichtring N (AL / AFM30)
Flat Sealing Ring N (AL / AFM 30)
Artikelnummer
Item Number
Artikelnummer
Item Number
Abmessungen
Dimensions
Artikelnummer
Item number
Abmessungen
Dimensions
15
457 00E10.8 061 002
54 55 90
ᴓ 42 x 49 x 2,0
73 74 89
21 x 26 x1,5
20
443 31.11.8 061 002
73 97 87
ᴓ 52 x 60 x 2,5
73 97 86
32 x 38 x 2
25
443 31.12.8 061 002
73 97 87
ᴓ 52 x 60 x 2,5
73 97 86
32 x 38 x 2
32
443 31.13.8 061 002
73 97 88
ᴓ 75 x 84 x 2,5
73 97 86
32 x 38 x 2
40
443 31.14.8 061 002
73 98 04
ᴓ 90 x 100 x 2,5
73 97 86
32 x 38 x 2
DN1
O-Ring S (CR85 sb) – nur Typ 455 / 457
O Ring Sealing S (CR85 sb) – Types 455 / 457 only
O-Ring S (PTFE) – nur Typ 456 / 458
O Ring Sealing S (PTFE) – Types 456 / 458 only
Artikelnummer
Item Number
Abmessungen
Dimensions
Artikelnummer
Item Number
Abmessungen
Dimensions
15
73 75 74
ᴓ 8 x 3
72 81 52
ᴓ 8 x 3
20
73 75 75
ᴓ 12 x 3
72 81 53
ᴓ 12 x 3
25
73 75 76
ᴓ 16 x 3
73 20 57
ᴓ 16 x 3
32
73 75 77
ᴓ 20 x 3
73 20 56
ᴓ 20 x 3
40
73 75 78
ᴓ 26 x 3
73 20 55
ᴓ 26 x 3
DN1
Dichteinheit kpl. – nur Typ 458
Sealing Unit cmpl. – Type 458 only
Dichteinheit kpl. – nur Typ 457
Sealing Unit cmpl. – Type 457 only
15
458 00E10.8 059 001
457 00E10.8 059 001
20
458 00E11.8 059 001
457 00E11.8 059 001
25
458 00E12.8 059 001
457 00E12.8 059 001
32
458 00E13.8 059 001
457 00E13.8 059 001
40
458 00E14.8 059 001
457 00E14.8 059 001
DN1
Spindelführung – nur Typ 455 / 456
Stem Guide – Types 455 / 456 only
O-Ring C (CR 75) – nur Typ 455 / 456
O Ring Sealing C (CR 75) – Types 455 / 456 only
Artikelnummer
Item Number
Artikelnummer
Item Number
Abmessungen
Dimensions
15
457 00E10.8 052 002
73 75 21
ᴓ 25 x 2
20
457 00E11.8 052 002
73 75 21
ᴓ 25 x 2
25
457 00E12.8 052 002
73 75 21
ᴓ 25 x 2
32
457 00E13.8 052 002
73 75 21
ᴓ 25 x 2
40
457 00E14.8 052 002
73 75 21
ᴓ 25 x 2
Ersatzteilliste
Spare Parts List
