Geberit HDPE - Jointing to Other Materials Using Adapters

29
Female iron BSP connector
Provides female iron connection to male iron BSP
threaded fittings. Body made from HDPE with a metal
reinforcing ring for butt welding onto standard Geberit
HDPE pipes and fittings.
Geberit HDPE adapter with female thread
Male iron BSP connector
Provides male iron connection to female iron threaded
BSP fittings. Body made from HDPE with a metal
reinforcing ring for butt welding onto standard Geberit
HDPE pipes and fittings.
Geberit HDPE adapter with male thread
Article no. dØ R
mm “
361.726.16.1 50 1
1
⁄4
361.727.16.1 50 1
1
⁄2
363.728.16.1 56 2
364.728.16.1 63 2
365.729.16.1 75 2
1
⁄2
Article no. dØ Rp
mm “
360.719.16.1 40
1
⁄2
360.720.16.1 40
3
⁄4
360.721.16.1 40 1
361.719.16.1 50
1
⁄2
361.720.16.1 50
3
⁄4
361.721.16.1 50 1
361.722.16.1 50 1
1
⁄4
361.723.16.1 50 1
1
⁄2
363.724.16.1 56 2
364.724.16.1 63 2
365.725.16.1 75 2
1
⁄2
Rp
H
d
R
H
d
4.9 Jointing Geberit drainage
systems to other materials
using adapters
Trap nut adapter
Reduces 1
1
⁄2” BSP nut to 1
1
⁄4” BSP size for connecting
to 1 1/4” BSP male iron waste outlets etc.
Geberit 1
1
⁄4 “ to 1
1
⁄2 “ BSP adapter
Loose nut adapter
Provides female BSP loose nut connection to male iron
BSP threaded fittings. Body made from HDPE for butt
welding onto standard Geberit pipes and fittings.
Geberit loose nut adapter with plastic screw connection
Article no. dØ G
mm “
152.175.16.1 40 1
1
⁄4
152.176.16.1 40 1
1
⁄2
152.179.16.1 50 1
1
⁄4
152.180.16.1 50 1
1
⁄2
152.181.16.1 50 2
152.184.16.1 32 1
1
⁄4
Article no. G
“
242.692.11.1 1
1
⁄2 x 1
1
⁄4
G
d
H
Geberit Drainage Systems
Jointing methods
