G-406-P11 SERVICE MANUAL PAGE 3
PPUH „GECO” Sp. z o.o. Edition I RELEASE DATE 2006-10-06
1. GENERAL CHARACTERISTICS
The self-dependent controller, hereafter called G-406-P11, is a convenient, modern and easy-to-
use equipment. It has been made in microprocessor based techniques, with the application of the
automatic surface assembly.
Depending on the installation method, the two-part casing provides the possibility of installing the control
panel operating under safe voltage practically everywhere, without the necessity of running power supply
cables far away from the equipment controlled.
The G-406-P11 controller has been equipped with:
• temperature sensors
1. for measuring the temperature of water leaving the boiler;
2. for measuring the temperature of the fuel feeder
3. flame optical sensor
The controller is equipped with 4 outputs allowing the direct connection of equipment operating
under the voltage of 230 V, such as fan, fuel feeding unit, central heating system pump and flame ignition
heater.
If the unit is to act as the central heating system boiler controller, the G-406-P11 stabilizes the
temperature of water and controls the process of fuel combustion in the boiler, preventing damping a fire.
The regulation parameters may be adjusted to current conditions of operation and kinds of the boiler. The
boiler has been equipped with the system of protection from the power failure or several kinds of
interference.
The controller does not require any maintenance, and the keyboard has been made from the special
kind of a film resistant to high-level temperatures and the majority of chemicals. The keyboard, however,
must not be cleaned with sharp edge objects. Instead, a humid cloth should be used for cleaning the front
panel.
In summertime, the controller should be kept connected to the power supply system, however, it
should be disconnected from the power for the period of storms.
2. TECHNICAL DATA
Operating voltage
⎯
230V +10% -15%
Temperature
⎯
From +5 °C to + 40 °C
Relative humidity
⎯
From 20% to 80%
Protection degree
⎯
IP65 on the front of the control panel
Output Maximum constant carrying capacity
P1 – Electric heater 4A 750W 1HP
P2 – C.H. pump 4A 750W 1HP
O – Container Feeder 4A 750W 1HP
W - Fan 3A 600W 1HP
Important:
The total current consumed by the equipment must not exceed 10A !!!
ª
