Rubbish Chute
Assembly and Operating Manual Page 14 of 24 BL041GB Edition 05.2012
4.2 Filling funnel
Item No.: 08922
Opening width
76 cm
Weight
8.5 kg
Item No.: 01921
Opening width
60 cm
Weight
8.8 kg
4.3 Chute branch
Item No.: 01922
Opening width
60 cm
Weight
10.5 kg
4.4 Hand winch Item No. 01907
Rope
5 mm, SE-Zn k – 1770 [sZ]
Rope length
21 m
Payload
250 kg
Weight
26 kg
