80209C_MHW_850-1650-1850_02-2020_ENG_pag. 186
4.30.3. MV.STA - Setting mV at start of scale
Acronym Scrolling message Submenu Attributes
MV.STA LINRZ.1 (o LINRZ.2) MV START SCALE LINRZ R W
The parameter shows and sets the value in millivolts at start of scale if the input is a thermocouple.
The parameter appears only if 32-step linearization has been selected (see paragraph “4.8.5. LIN – Selecting linearization
type” on page <?>)
Unit of measurement: mV
Options: -19.99...99.99
4.30.4. MV.FUL - Setting mV at full scale
Acronym Scrolling message Submenu Attributes
MV.FUL LINRZ.1 (o LINRZ.2) MV FULL SCALE LINRZ R W
The parameter shows and sets the value in millivolts at full scale if the input is a thermocouple.
The parameter appears only if 32-step linearization has been selected (see paragraph “4.8.5. LIN – Selecting linearization
type” on page <?>)
Unit of measurement: mV
Options: MV.STA + 1...99.99
4.30.5. MV.50c - Setting mV at temperature of 50 °C
Acronym Scrolling message Submenu Attributes
MV.50C LINRZ.1 (o LINRZ.2) MV AT 50 ‘C LINRZ R W
The parameter shows and sets the value in millivolts at 50°C if the input is a thermocouple.
The parameter appears only if 32-step linearization has been selected (see paragraph “4.8.5. LIN – Selecting linearization
type” on page 82)
Unit of measurement: mV
Options: -1.999...9.999
