4.4.24. OUT1 - Type of output 1
Acronym Scrolling message Submenu Attributes
Out1 OUTPUT TYPE INFO R
The parameter specifies the type of output 1.
Unit of measurement: -
Options: RELAY = Relay output
DIGIT = 24 V logic output
CONT.A = Continuous output configurable in current and voltage (model 850 only).
CONT.C = Continuous output in current (models 1650 and 1850 only).
4.4.25. OUT2 - Type of output 2
Acronym Scrolling message Submenu Attributes
Out2 OUTPUT TYPE INFO R
If present, the parameter indicates that output 2 is available on the controller and specifies the type.
Unit of measurement: -
Options: RELAY = Relay output
DIGIT = 24 V logic output
MOS = Optomos isolated logic output
4.4.26. OUT3 - Type of output 3
Acronym Scrolling message Submenu Attributes
Out3 OUTPUT TYPE INFO R
If present, the parameter indicates that output 3 is available on the controller and specifies the type.
Unit of measurement: -
Options: RELAY = Relay output
DIGIT = 24 V logic output
MOS = Optomos isolated logic output
TRIAC = Triac output (only for model 850)
VT24 = Power supply output for transmitter (models 1650 and 1850 only).
4.4.27. OUT4 - Type of output 4
Acronym Scrolling message Submenu Attributes
Out4 OUTPUT TYPE INFO R
If present, the parameter indicates that output 4 is available on the controller and specifies the type.
Unit of measurement: -
Options: RELAY = Relay output
DIGIT = 24V logic output (model 850 only)
TRIAC = Triac output (only for models 1650 and 1850)
4.4.28. OUT1.S - Number of switchings output 1
Acronym Scrolling message Submenu Attributes
OUT1.S NUMBER X 1000 RELAY CYCLES INFO R
If output 1 is relay or logic, the parameter shows the number of switchings (in thousands).
Unit of measurement: Number (× 1000)
Options: -
