ADL500 • Quick installation guide - Specifications and connection 67
Step 4 – Setting mechanical system data
STARTUP WIZARD
Set mechanical data?
E=Yes Down=Next
E
01 /09
PAR: 11002
Travel unit sel
Hz
Value: 0

Available selections:
0 Hz (output frequency)
1 m/s (cabin speed, depends on the mechanical constant )
2 Rpm (motor shaft speed )
3 USCS (US unit of measure: fpm, ft/s
2
, ft/s
3
)
 
02 /09
PAR: 11006
Cabin speed
1.00 m/s
Def: 1.0

Range: 0 ... 10
 
03 /09
PAR: 11010
Gearbox ratio
45.000
Def: 45.000

Range: 1 ... 200
 
04 /09
PAR: 11164
Rope ratio
1
Def: 1

Range: 1 ... 40
 
05 /09
PAR: 11012
Pulley diameter
0.600 m
Def: 0.600

Range: 0 ... 5
 
06 /09
PAR: 11150
Car wei
g
ht
400 kg
Def: 400

Range: 0 ... 10000
 
07 /09
PAR: 11052
Counter wei
g
ht
1000 kg
Def: 1000

Range: 0 ... 10000
 
08 /09
PAR: 11154
Load wei
g
ht
450 kg
Def: 450

Range: 0 ... 100,000
 
09 /09
PAR: 11156
Rope wei
g
ht
20 kg
Def: 20

Range: 0 ... 10000
At the end of the procedure proceed to next step.
