ADL500 • Quick installation guide - Specifications and connection 69
Through the combination of “MtlSpd S0” (Digital input 4), “MtlSpd S1” (Digital input 5) and “MtlSpd S2” (Digital input
6) commands, is possible to select Multi speed desired, according to next table:
MtlSpd S2 MtlSpd S1 MtlSpd S0 ACTIVE SPEED
0 0 0 Multispeed 0, PAR 11020
0 0 1 Multispeed 1, PAR 11022
0 1 0 Multispeed 2, PAR 11024
0 1 1 Multispeed 3, PAR 11026
1 0 0 Multispeed 4, PAR 11028
1 0 1 Multispeed 5, PAR 11030
1 1 0 Multispeed 6, PAR 11032
1 1 1 Multispeed 7, PAR 11034
At the end of the procedure proceed to next step.
Step 6 – Autotune with motor at stand-still
The drive carries out the motor autotune procedure (real measurement of motor parameters).
The procedure is fast and recommended in most cases
Note ! If this operation generates an error message, check the connections o the power and control circuits (see step 1 - Connections), check the motor data set-
tings (see step 3 - Setting motor parameters) and then repeat the guided Autotune procedure.
STARTUP WIZARD
Run autotune still?
E=Yes Down=Next
E
01 /01
PAR: 2032
Autotune
Press E to execute
E
Autotune
Progress 0%
Close Enable Input
E
(1) (2) (3)
Autotune
Progress 10%
Press ESC to abort
E
Autotune
Progress 100%
Open Enable input
Autotune
Done
(4) (5)
(1) Press the E key to proceed to the autotune procedure.
(2) Press the E key to start the autotune procedure.
(3) Enable the drive by connecting terminal 9 (Enable) to terminal 12 (+24 V). To abort this operation, press the ESC
key.
(4) Once the drive is enabled the autotune procedure starts. This may take a few minutes, depending on the type of
motor being used.
(5) At the end of the procedure the following screen is displayed. After opening the Enable contact, go to next step.
Note ! At the end of the autotune procedure there is a request to open the Enable contact (terminals 9 - 12); this results in the automatic execution of the Take tune
parameters command (menu MOTOR DATA, PAR: 2078).
The calculated parameters are saved in a RAM memory to enable the drive to perform the necessary calculations. These data are lost if the device is
switched off. To save the motor data follow the procedure described in step 7.
