72 ADL500 • Quick installation guide - Specifications and connection
03 /07
PAR: 2100
Encoder pulses
1024 ppr
Def: 1024
Range: 4 ... 16384
04 /07
PAR: 2110
Encoder signal check
Check A-B
Value: 1
Available selections:
(1) Check A-B
(2) Check A-B-Z
At the end of the procedure proceed to next step.
Step 3 – Setting motor parameters
Note !
Def: The factory (default) setting depends on the size of the drive that is connected. These values refer to the size ADL5.-1055
STARTUP WIZARD
Set motor data?
E=Yes Down=Next
E
01 /09
PAR: 540
Control type
SYN FOC
Value: 2
Available selections:
(2) SYN FOC
02 /09
PAR: 2000
Rated voltage
340 v
Def: 400
Range: 230 ... 480V
03 /09
PAR: 2002
Rated current
17.5 a
Def: 11.8
Range: 1 ... 1500A
04 /09
PAR: 2004
Rated speed
144 rpm
Def: 1450
Range: 10 ... 32000rpm
06 /09
PAR: 2008
Pole pairs
12
Def: 2
Range: 1 ... 60
09 /09
PAR: 2014
Torque constant
50.00 Nm/a
Def: 50.00
Range: -
Set the plate data of the motor connected, following the instructions given on the previous pages
.
Rated voltage [V]: the rated voltage of the motor indicated on the data plate.
Rated current [A]: motor rated current; approximately, the value should not be less than 0.3 times the rated current of the drive, output current
class 1 @ 400 V on the data plate of the drive.
Rated speed [rpm]: motor rated speed; see data plate.
Pole pairs: Number of motor pole pairs; see data plate.
Torque constant [Nm/a] : (KT) Ratio between the torque generated by the motor and the current required to supply it.
Note ! When data entry is complete the Take parameters command is executed automatically (menu MOTOR DATA, PAR: 2020). The motor data entered during the
STARTUP WIZARD procedure are saved in a RAM memory to enable the drive to perform the necessary calculations.
