ADL500 • Quick installation guide - Specifications and connection 73
These data are lost if the device is switched off. To save the motor data follow the procedure described in step 8.
At the end of the procedure proceed to next step.
Step 4 – Setting mechanical system data
STARTUP WIZARD
Set mechanical data?
E=Yes Down=Next
E
01 /09
PAR: 11002
Travel unit sel
Hz
Value: 0

Available selections:
0 Hz (output frequency)
1 m/s (cabin speed, depends on the mechanical constant )
2 Rpm (motor shaft speed )
3 USCS (US unit of measure: fpm, ft/s
2
, ft/s
3
)
 
02 /09
PAR: 11006
Cabin speed
1.00 m/s
Def: 1.0

Range: 0 ... 10
 
03 /09
PAR: 11010
Gearbox ratio
45.000
Def: 45.000

Range: 1 ... 200
 
04 /09
PAR: 11164
Rope ratio
1
Def: 1

Range: 1 ... 40
 
05 /09
PAR: 11012
Pulley diameter
0.600 m
Def: 0.600

Range: 0 ... 5
 
06 /09
PAR: 11150
Car wei
g
ht
400 kg
Def: 400

Range: 0 ... 10000
 
07 /09
PAR: 11052
Counter wei
g
ht
1000 kg
Def: 1000

Range: 0 ... 10000
 
08 /09
PAR: 11154
Load wei
g
ht
450 kg
Def: 450

Range: 0 ... 100,000
 
09 /09
PAR: 11156
Rope wei
g
ht
20 kg
Def: 20

Range: 0 ... 10000
At the end of the procedure proceed to next step.
