User Guide Electrical Line Shaft for ADV200 Page 17 of 72
Parameter Name
User type
Value
Unit
Min
Max
Access
11018 Els Master Sel
Enumerative
Encoder 1
Encoder 2 (def)
Encoder 3
Fast Link
Virtual Enc
-
-
-
RWZ
Selector for source of reference master. By selecting Virtual Enc, the reference master of the drive becomes a virtual
encoder generated by the application itself and is available to the next slaves in the chain.
11020 Els Master PPR
Unsigned short
1024
ppr
ERWZ
Pulses of the reference master encoder. The parameter must be set when Els Master Sel = Fast Link or Virtual Enc.
11098 Els Enc V Max Speed
Float
2000
rpm
50
32000
ERW
Maximum speed generated by virtual master.
11100 Els Enc V Speed
Float
0
rpm
ERW
Speed reference of virtual master.
11102 Els Enc V Acc Time
Float
1.00
s
0.01
10
ERW
Acceleration ramp from 0 to Els Enc V Max Speed.
11104 Els Enc V Dec Time
Float
1.00
s
0.01
10
ERW
Deceleration ramp from Els Enc V Max Speed to 0.
11106 Els Enc V Ovr src
Enumerative
Null (def)
Analog input x
Analog input xX
-
-
-
ERWZ
Selector for source of speed reference override of virtual encoder.
If other than Null, you can (via analog input) modulate the speed reference from - Els Enc V Speed to Els Enc V Speed
between the top and bottom system limits of the selected input.
Note: with the speed override function you can invert the direction of rotation of the master without having to use the
inversion command.
11108 Els Master Pos dest
Enumerative
Null (def)
Pad from 1 to 16
-
-
-
ERWZ
Selector for destination of monitor of virtual position of reference master Els Master Pos mon.
11110 Els Master Rev dest
Enumerative
Null (def)
Pad from 1 to 16
-
-
-
ERWZ
Selector for destination of monitor of virtual revolutions of reference master Els Master Rev mon.
11112 Els Enc V Run Fw src
Enumerative
Null (def)
Dig inp x
Decomp
Dig inp x X
-
-
-
ERWZ
Selector of source of Run Forward command to generate speed of virtual encoder (active on level).
If activated simultaneously with the Run Reverse command, the speed of the virtual encoder remains 0.
If activated without the Run Reverse command, the speed of the virtual encoder goes to ramp at Els Enc V Speed.
If activated in the presence of the Run Reverse command, it has no effect on the current command.
11114 Els Enc V Run Rv src
Enumerative
Null (def)
Dig inp x
Decomp
Dig inp x X
-
-
-
ERWZ
Selector of source of Run Reverse command to generate speed of virtual encoder (active on level).
If activated simultaneously with the Run Forward command, the speed of the virtual encoder remains 0.
If activated without the Run Forward command, the speed of the virtual encoder goes to – Els Enc V Speed.
If activated in the presence of the Run Forward command, it has no effect on the current command.
12014 Els Master Rev mon
Long
-
cnt
-
-
R
Monitor of number of virtual revolutions of reference master encoder.
12016 Els Master Pos mon
Long
-
-
-
-
R
Monitor of virtual position in encoder rev of reference master.
12018 Els Master Speed mon
Float
-
rpm
-
-
R
Monitor of speed of reference master (unfiltered).
