User Guide Electrical Line Shaft for ADV200 Page 22 of 72
Parameter Name
User type
Value
Unit
Min
Max
Access
11062 Els Ratio Sel src
Enumerative
Parameter (def)
Digital
-
-
-
RW
Selector for source to select Slave/Master slip ratio.
If set to Parameter (default), the ratio in use is selected with parameter Els ratio Index.
If set to Digital, the ratio in use is selected with digital inputs Els Ratio Sel b0 and/or Els Ratio Sel b1 according to a
binary configuration:
Els Ratio Sel b1
Els Ratio Sel b0
Els Actual Ratio
0
0
Els Ratio 0
0
1
Els Ratio 1
1
0
Els Ratio 2
1
1
Els Ratio 3
11064 Els Ratio Index
Enumerative
Ratio 0 (def)
Ratio 1
Ratio 2
Ratio 3
-
-
-
RW
Ratio selection parameter when Els Ratio Sel src = Parameter.
11066 Els Ratio Sel b0 src
Enumerative
Null (def)
Dig inp x
Decomp
Dig inp x X
-
-
-
ERWZ
Selector for source of digital selection command of ratio bit 0 when Els Ratio Sel src = Digital.
11068 Els Ratio Sel b1 src
Enumerative
Null (def)
Dig inp x
Decomp
Dig inp x X
-
-
-
ERWZ
Selector for source of digital selection command of ratio bit 1 when Els Ratio Sel src = Digital.
11070 Els Ratio 0
Float
1.000
-
-200
+200
RW
Rapporto di velocità Slave/Master 0.
11072 Els Ratio 0 AccTime
Float
1.000
s
0
10
ERW
Acceleration ramp at change of Ratio 0.
Corresponds to the time needed to accelerate from 0 to the speed set in parameter Speed ref top lim (IPA 670 on
REFERENCES menu).
11074 Els Ratio 0 DecTime
Float
1.000
s
0
10
ERW
Deceleration ramp at change of Ratio 0.
Corresponds to the time needed to decelerate from the speed set in parameter Speed ref top lim (IPA 670 on
REFERENCES menu) to 0.
11076 Els Ratio 1
Float
1.000
-
-200
+200
RW
Slave/Master speed ratio 1.
11078 Els Ratio 1 AccTime
Float
1.000
s
0
10
ERW
Acceleration ramp at change of Ratio 1.
Corresponds to time needed to accelerate from 0 to the speed set in parameter Speed ref top lim (IPA 670 on
REFERENCES menu).
11080 Els Ratio 1 DecTime
Float
1.000
s
0
10
ERW
Deceleration ramp at change of Ratio 1.
Corresponds to time needed to decelerate from the speed set in parameter Speed ref top lim (IPA 670 on REFERENCES
menu) to 0.
11082 Els Ratio 2
Float
1.000
-
-200
+200
RW
Slave/Master speed ratio 2.
11084 Els Ratio 2 AccTime
Float
1.000
s
0
10
ERW
Acceleration ramp at change of Ratio 2.
Corresponds to time needed to accelerate from 0 to the speed set in parameter Speed ref top lim (IPA 670 on
REFERENCES menu).
