User Guide Electrical Line Shaft for ADV200 Page 23 of 72
11086 Els Ratio 2 DecTime
Deceleration ramp at change of Ratio 2.
Corresponds to time needed to decelerate from the speed set in parameter Speed ref top lim (IPA 670 on REFERENCES
menu) to 0.
Slave/Master speed ratio 3.
11090 Els Ratio 3 AccTime
Acceleration ramp at change of Ratio 3.
Corresponds to time needed to accelerate from 0 to the speed set in parameter Speed ref top lim (IPA 670 on
REFERENCES menu).
11092 Els Ratio 3 DecTime
Deceleration ramp at change of Ratio 2.
Corresponds to time needed to decelerate from the speed set in parameter Speed ref top lim (IPA 670 on REFERENCES
menu) to 0.
11096 Els Ratio Reach dest
Pad from 1 to
Selector for destination of monitor of selected ratio state reached Els Ratio Reach mon.
12040 Els Ratio Sel bit 0 mon
Monitor of state of command for digital selection of ratio, bit 0.
12042 Els Ratio Sel bit 1 mon
Monitor of state of command for digital selection of ratio, bit 1.
Ratio between Slave/Master speeds in use
12046 Els Actual Ratio Acc
Acceleration ramp on ratio between Slave/Master speeds in use
12048 Els Actual Ratio Dec
Deceleration ramp on slip ratio between Slave/Master speeds in use
12052 Els Ratio Reach mon
Monitor of state of selected ratio reached.
Becomes Off at a change of ratio, goes to ON at end of new ratio change ramp. New set ratio reached.
Monitor of overall chain of Slave/Master ratio in use
Value calculated with formula:
Els Act mech Ratio * Els Act Ratio * ( 1 + Els Actual Slip mon / 100 )
Els Act mech Ratio is displayed on MECH RATIO menu
Els Actual Slip mon is displayed on SLIP RATIO menu
