GT-SER 2
SERIAL COMMUNICATION MODULE
Main applications
• ConnectionofGefranindustrial
 PCstoRS-232,RS-485,RS-422
network
Main characteristics
• Configurableoptically-isolatedserial
 ports
• Selectableinterfaces:RS-232,RS-485,
RS-422
• COM3connector:D-Sub9pinmale
• COM4connectors:RJ10
• Highcommunicationspeed:from
 9.6kBaudto115kBaud
PROFILE
GT-SER2isaserialbusexpansion
moduleforindustrialPCsandfor
DigistarIIandGT-Ccontroltermi-
nals.
Itprovides2opticallyisolatedserial
channelsprotectedagainstovervol-
tages.
Itperformscontrolandinterfacesthe
communicationnetworkwithRS-232,
RS-485,RS-422standards,selecta-
blewithDIP-Switches.
TheserialconnectionusesaD-Sub9
pinmaleconnectorforCOM3andan
RJ104pinconnectorforCOM4.
IntheDigistarII,GT-CandGFBOX
terminals,theexpansionmodule
insertsintheexpansion2customslot
(EXP2).
TECHNICAL DATA
• 2 configurable optically-isolated serial
ports
• DIP-Switches to configure RS-232,
RS-485, RS-422 and to enable automa-
tic transmission/reception and from
software via dip-switch
• Connectors: COM3 D-Sub 9 pin male,
COM4 RJ10 4 pin
• High communication speed: from
9.6 kBaud to 115 kBaud
• Configurable terminations and polarisa-
tions
Mechanical characteristics
• Dimensions: 60x20x80 mm
• Weight (*): 51g (including anti-static
bag supplied as standard)
• Fastening: screw
• Connector for connection to Gefran
industrial PCs
aMbient conditions
• Working temperature: 0…50°C
• Storage temperature: -20…70°C
• Humidity: 90% RH max.,
non-condensing
Installation and Connections
The GT-SER 2 expansion module installs
in Gefran Digistar II, GT-C and GF-BOX
industrial PCs in slot EXP 2.
