19
80546B_MHW_GF_VEDO-HL_02-2013_ENG
Figure 21 - Access to internal resources of GF_VEDO HL terminals
3.6.1 System memory: SODIMM
GF_VEDO HL has a DDR1 SODIMM (Small Outline Dual In-line Memory Module) system memory, which is more
compact than normal DIMM.
3.6.2 Mass memory: DOM
GF_VEDO HL terminals are equipped with mass memory that contains the operating system and user data.
Each terminal has a solid state disk with Disk On Module (DOM) IDE AT compatible interface.
3.6 Access to internal system resources
You can replace the battery and configure the COM3 serial by removing the rear cover of the terminal as shown in
Figure 21. TURN OFF the GF_VEDO HL terminal before loosening the screws.
