Fixing
Panel mounting of GF_VEDO HL
GF_VEDO HL panels are designed for front panel installation.
After making the opening shown on the template drawing, fasten the GF_VEDO HL with the blocks required and
supplied with the product.
Figure 3 - Panel mounting GF_VEDO HL 121CT
Figure 4 - Panel mounting GF_VEDO HL 150CT
