5 • SUMMARY OF CHARACTERISTICS
Model GF_VEDO HL 121CT GF_VEDO HL 150CT
Display
Type TFT Colors
No colours 262k
Size 12.1” 15.0”
Display area (mm) 246.0x184.5 304.1x228.1
Resolution SVGA 800x600 XVGA 1024x768
Luminosity 450 cd/m
2
350 cd/m
2
Contrast 1000:1 700:1
Backlighting [/MTBF(h)] CCFL/50000
Visual angle O/V 178°/178° 140°/120°
Touch Screen
Type Resistive 4 wires
Life >1M operations
Controller integrated
Processor
Frequency Intel Celeron
TM
M 600MHz
Intel Celeron
TM
M1500MHz
Core x86
Memory
System Memory (DRAM) 256MB - 1GB
Mass Memory (DOM) 128MB - 1GB - 4GB
I/O Peripherals
PS2 Keyboard/Mouse 6-pin miniDIN connector (green: Mouse - purple: Keyboard)
USB 2 x USB 2.0 Host (500mA) (4-pin type A connector)
Ethernet ETH1 - ETH2 2 x Ethernet 10/100 Mbps (RJ45 with LED)
KEY & LED RJ45 connector without LED
AUTOSTART(optional) 3-pin female connector, screw-type
COM1 1 x RS485 optically isolated from 9.6 to 115kBaud (D-Sub 9 PM)
COM2 (optional) 1 x RS232 not optically isolated from 9.6 to 115kBaud (D-Sub 9 PM)
COM3 Configurable
(optional)
Default RS485 (optically isolated) / RS422 (optically isolated) / RS232
(not optically isolated) da 9.6 a 115kBaud (D-Sub 9 PM)
CAN 1 x CANopen from 9.6 to 115kBaud (D-Sub 9 PM)
Terminations insertable from outside
External Battery 3,6V external battery (2-pin connector)
Operative systems VxWorks or WindowsXP Embedded
Various
Power supply 24VDC ±25% (6-pin female connector)
Max consumption at 24VDC 2,5A 2,5A
Resettable fuses Protected against overcurrent on input circuit
Battery 3V, 270mA/h lithium, non-rechargeable internal at terminals Model: CR2430 button
RTC hardware clock Clock/calendar with buffer battery
Faceplate protection IP65 (IEC 529)
Certifications CE, UL (pending)
Dimensions
Faceplate (mm) 305x231 369x272.85
Drilling (mm) 295x222 363x262.5
Max panel thickness (mm) 4 4
Weight (Kg) 2.9 3.2
Operating/Storage condition
Operating temperature Mod. PCE 600MHz 0 ... 45°C
Mod. PCS 1500MHz 0 ... 40°C
Storage temperature -20° ... +70°C (IEC 68-2-14)
Operating/storage humidity 5 ... 95% UR non condensing (IEC 68-2-3)
