State of output OUT10
OFF = Output Off
ON = Active output
R
State of output OUT9
OFF = Output Off
ON = Active output
R
State of output OUT8
OFF = Output Off
ON = Active output
R
State of output OUT7
OFF = Output Off
ON = Active output
R
State of output OUT6
OFF = Output Off
ON = Active output
R
State of output OUT5
OFF = Output Off
ON = Active output
R
State of output OUT4
OFF = Output Off
ON = Active output
R
State of output OUT3
OFF = Output Off
ON = Active output
R
State of output OUT2
OFF = Output Off
ON = Active output
R
State of output OUT1
OFF = Output Off
ON = Active output
R
Read state
664
R
State of outputs
bit
0 OUT 1
1 OUT 2
2 OUT 3
3 OUT 4
4 OUT 5
5 OUT 6
6 OUT 7
7 OUT 8
8 OUT 9
9 OUT 10
607
ovt.1
R/W
Allocation of physical output OUT 1
1
0 Output disabled
1 Output rL.1 zone 1
2 Output rL.1 zone 2
3 Output rL.1 zone 3
4 Output rL.1 zone 4
5 Output rL.2 zone 1
6 Output rL.2 zone 2
7 Output rL.2 zone 3
8 Output rL.2 zone 4
9 Output rL.3 OR rL.5 zone 1
10 Output rL.3 OR rL.5 zone 2
11 Output rL.3 OR rL.5 zone 3
12 Output rL.3 OR rL.5 zone 4
13 Output rL.4 AND rL.6 zone 1
14 Output rL.4 AND rL.6 zone 2
15 Output rL.4 AND rL.6 zone 3
16 Output rL.4 AND rL.6 zone 4
17 Output (rL.3 OR rL.5) zone 1...zone 4
18 Output (rL.4 AND rL.6) zone 1...zone 4
Table of output allocations
NOTE: In 3-phase conguration, the state of physical output OUT1 is copied
to OUT2 and OUT3.
In case of COOL OUTPUT (5,6,7,8) are continuous, the same output functions
can not be used on other outputs.
Ex: If out.1 = 1 (out rL.1 zone 1) it is not possible to set out.5 with the same
code, if out.5 is continuous
608
ovt.2
R/W
Allocation of physical output OUT 2
2
609
ovt.3
R/W
Allocation of physical output OUT 3
3
610
ovt.4
R/W
Allocation of physical output OUT 4
4
611
ovt.5
R/W
Allocation of physical output OUT 5
5
612
ovt.6
R/W
Allocation of physical output OUT 6
6
613
ovt.7
R/W
Allocation of physical output OUT 7
7
614
ovt.8
R/W
Allocation of physical output OUT 8
8
615
ovt.9
R/W
Allocation of physical output OUT 9
17
616
ovt.10
R/W
Allocation of physical output OUT 10
18
ALLOCATION OF PHYSICAL OUTPUTS
+32 to reverse output status only for Logic and Relay output
