gefran GFX4-IR Configuration And Programming Manual

36
80415F_MSW_GFX4-IR_05-2019_ENG
ALARM SBR - ERR (probe in short or connection error)
This alarm is always ON and cannot be deactivated. It controls correct functioning of the probe connected to the main
input.
In case of broken probe:
- the state of alarms AL1, AL2, AL3 and AL4 is set based on the value of parameter rEL;
- control power control is set to the value of parameter FAP.
Identification of the type of break detected on the main input is contained in Err.
9
bit
STATE OF INPUT
IN SBR
OFF = -
ON = Input in SBR
R
Enable alarm
229
rEL
R/W
Fault action
(definition of state in case
of broken probe)
Sbr, ERR
Only for main input
0
Alarm1 Alarm2 Alarm3 Alarm4
0 OFF OFF OFF OFF
1 ON OFF OFF OFF
2 OFF ON OFF OFF
3 ON ON OFF OFF
4 OFF OFF ON OFF
5 ON OFF ON OFF
6 OFF ON ON OFF
7 ON ON ON OFF
8 OFF OFF OFF ON
9 ON OFF OFF ON
10 OFF ON OFF ON
11 ON ON OFF ON
12 OFF OFF ON ON
13 ON OFF ON ON
14 OFF ON ON ON
15 ON ON ON ON
Table of probe alarm settings
228
fa.p
R/W
Fault action power
(supplied in conditions of broken probe)
-100.0 ..100.0 %
0.0
see: HOT RUNNERS CONTROL
Read state
85
Err
R
Error code in self-diagnostics
of main input
See: Table of error codes
