gefran GFX4-IR Configuration And Programming Manual

62
80415F_MSW_GFX4-IR_05-2019_ENG
730
xd.6
R/W
Enable feedback modes
0
Table feedback modes
0.0 ...100.0 %
0 None
1 V
2
(Voltage)
2 I
2
(Current)
3 P (Power)
4 None
5 V (Linear voltage)
6 I (Linear current)
731
(OR.V
R/W
Maximum correction of voltage feedback
100.0
0.0 ...100.0 %
732
(OR.i
R/W
Maximum correction of current feedback
100.0
0.0 ...100.0 %
733
(OR.p
R/W
Maximum correction of power feedback
100.0
0.0 ...999.9 V
734
Rif.V
R/W
Voltage feedback reference
0.0
0.0 ...999.9 A
735
Rif.i
R/W
Current feedback reference
0.0
0.0 ...99.99 kW
736
Rif.p
R/W
Power feedback reference
0.0
113
bit
Calibration of voltage
feedback reference
R/W
OFF = Calibration not enabled
ON = Calibration enabled
NOTE: For other information see the
hardware manual
READ STATE
464
R/W
STATUS 11_W
0
Table settings STATUS 11_W (*)
bit
5 Feedback calibration
6 HB alarm calibration
(*) To safeguard the other bit, writing should
be done starting from the reading going to
change only the bit interested.
741
fb.It
R/W
Feedback response speed
0.1 ...5.0
% / 60msec
0.3
757*
ARif
R
Reference of Feedback
Setpoint of V, I, P to maintain
on load
0.0 ...999.9 A
0.0 ...99.99 kW
0.0 ...999.9 V
