gefran GFX4-IR Configuration And Programming Manual

7380415F_MSW_GFX4-IR_05-2019_ENG
AUXILIARY ANALOG INPUT (LIN/TC)
194
AI.2
R/W
Select type of auxiliary input sensor
181
tp.2
R/W
Definition of auxiliary analog input
function
677
dP.2
R/W
Decimal point position for auxiliary input
scale
404
LS.2
R/W
Minimum limit auxiliary input scale
603
XS.2
R/W
Maximum limit auxiliary input scale
605
oFS.2
R/W
Offset correction for auxiliary input
604
FLt.2
R/W
Digital filter for auxiliary input
602
In.2
R
Value of auxiliary input
606
Er.2
R
Self-diagnosis error code of auxiliary
input
LINE VOLTAGE VALUE
411
o.tU1
R/W
Offset correction voltmeter transformer
input TV (phase 1)
419
o.tU2
R/W
Offset correction voltmeter transformer
input TV (phase 2)
with three-phase load
420
o.tU3
R/W
Offset correction voltmeter transformer
input TV (phase 3)
with three-phase load
412
FT.TU
R/W
Digital filter TV auxiliary input
(phase 1, 2, 3)
492
1.tU2
R
Voltmeter input value (phase 2)
493
1.tU3
R
Voltmeter input value (phase 3)
232
485
1.tU1
R
Voltmeter input value (phase 1)
496
1.UF2
R
Voltmeter input value (phase 2)
497
1.UF3
R
Voltmeter input value (phase 3)
322
1.UF1
R
Voltmeter input value (phase 1)
710
1.U21
R
Linked voltage V21
711
1.U32
R
Linked voltage V32
315
FrEq
R
Voltage frequency in tenths of Hz
712
1.U13
R
Linked voltage V13
702
voltage status
POWER ON LOAD
720
LD.P.T
R
Power on 3-phase load
749
LD.I
R
Impedance on load
719
LD.P
R
Power on load
750
LD.I.T
R
Impedance on 3-phase load
