gefran GFX4-IR Configuration And Programming Manual

7780415F_MSW_GFX4-IR_05-2019_ENG
26
bit
STATE OF HB ALARM or
POWER_FAULT
OFF = Alarm off
ON = Alarm on
R
76
bit
State of HB alarm
phase 1
R
77
bit
State of HB alarm
phase 2
with 3-phase load
R
78
bit
State of HB alarm
phase 3
with 3-phase load
R
512
R
States of alarm ALSTATE
(for single-phase loads)
504
R
States of alarm HB ALSTATE_HB
(for 3-phase loads)
744
xb.tr
R
HB alarm setpoint as function of
power on load
759
Ir.01
R/W
HB Calibration with IR lamp: current at
50% conduction
758
Ir.00
R/W
HB Calibration with IR lamp: current at
100% conduction
743
xb.Pw
R
Ou.P power in HB calibration
742
xb.tA
R
CT read in HB calibration
760
Ir.02
R/W
HB Calibration with IR lamp: current at
30% conduction
761
Ir.03
R/W
HB Calibration with IR lamp: current at
20% conduction
HB ALARM (Heater Break Alarm)
57
Xb.f
R/W
HB alarm function
195
AL.n
R/W
Select number of enabled alarms
with 3-phase load
55
A.xb1
R/W
HB alarm setpoint (ammeter input scale
points - Phase 1)
56
XB.T
R/W
Delay time for HB alarm activation
502
A.xb2
R/W
HB alarm setpoint (ammeter input scale
points - Phase 2)
with 3-phase load
737
xb.P
R/W
Percentage HB alarm setpoint of current
read in HB calibration
112
bit
Calibration HB alarm
setpoint
OFF = Calibration not enabled
ON = Calibration enabled
R/W
464
R/W
STATUS 11_W
767
Ir.04
R/W
HB Calibration with IR lamp
(only for PA modality): current at 15%
conduction
768
Ir.05
R/W
HB Calibration with IR lamp
(only for PA modality): current at 10%
conduction
769
Ir.06
R/W
HB Calibration with IR lamp
(only for PA modality): current at 5%
conduction
318
R
ALSTATE IRQ alarms state
