Maximum scale limit of voltage
transformer TV input (phase 3)
0.0 ... 999.9
530,0
With 3-phase load
417
x.tU2
R/W
Maximum scale limit of voltage
transformer TV input (phase 2)
0.0 ... 999.9
530,0
With 3-phase load
420
o.tU3
R/W
Offset correction for TV input
(phase 3)
-99.9 ...99.9
Scale points
0,0
With 3-phase load
419
o.tU2
R/W
Offset correction for TV input
(phase 2)
-99.9 ...99.9
Scale points
0,0
With 3-phase load
Input lter
Setting the offset
Scale limits
493
1.tU3
R
Value of voltmeter input (phase 3)
With 3-phase load
492
1.tU2
R
Value of voltmeter input (phase 2)
With 3-phase load
232
485
1.tU1
R
Value of voltmeter input (phase 1)
410
x.tU1
R/W
Maximum scale limit of voltage
transformer TV input (phase 1)
0.0 ... 999.9
530,0
411
o.tU1
R/W
Offset correction for TV input
(phase 1)
-99.9 ...99.9
Scale points
0,0
Read state
ADVANCED SETTINGS
FUNCTIONAL DIAGRAM
412
FT.TU
R/W
Digital filter for auxiliary TV input (phase
1, 2 and 3)
0.0 ... 20.0 sec.
0.0
Sets a low pass lter on the auxiliary TV input, running the average of values read in the
specied time interval. If = 0 , excludes the average lter on sampled values.
TV1 auxiliary
input
Scale limits for
offset
(H.tV1, o.tV1)
Low pass
lter
(Ft.tV)
Internal variable I.tV1
See generic alarms
