gefran GFX4 Configuration And Programming Manual

60
880397M_MSW_GFX4-GFXTERMO4_08-2018_ENG
HW/SW INFORMATION
The following data registers can be used to identify the controller HW/SW and check its operation.
122
UPD
R
Software version code
606
Er.2
R
Self-diagnosis
error code for auxiliary input
0 No Error
1 Lo (process variable value < Lo.S)
2 Hi (process variable value > Hi.S)
3 ERR [third wire interrupted for PT100 or input values below minimum
limits (ex. for TC with connection error)]
4 SBR (probe interrupted or input values beyond maximum limits)
85
Err
R
Self-diagnosis
error code for main input
Table of main input errors
190
(.xd
R Hardware configuration codes
(*) In correspondence to the SV value on the GFX-OP display, the digits indicate bit
values as follows:
- THOUSANDS and HUNDREDS
(Power GFX4 / GFXTERMO4) correspond to bits 6 to 9
- TENS (COOL outputs) correspond to bits 1 to 4
- ONES (Number of CT) correspond to bits 10 to 14
bit Value indicated
by GFX-OP (*)
0 = 1 OUTPUT COOL absent 0
1 = 1 OUTPUT COOL relay r
2 = 1 OUTPUT COOL logic d
3 = 1 OUTPUT COOL continuous 0...20mA / 0...10V t
4 = 1 OUTPUT COOL triac 250Vac 1A c
5 -
6 = 1 GFX4 absent (GFXTERMO4 present) te
7 = 1 GFX4 30 kW 30
8 = 1 GFX4 60 kW 60
9 = 1 GFX4 80 kW 80
10 = 1 GFX4 without TA 0
11 = 1 GFX4 with 1 TA 1
12 = 1 GFX4 with 4TA 4
13 = 1 GFXTERMO4 without TA 0
14 = 1 GFXTERMO4 with 4TA 4
Table of hardware conguration codes
508
(.xd1
R Hardware configuration codes 1
(*) In correspondence to the SV value on the GFX-OP display, the digits indicate bit
values as follows:
- TENS (auxiliary inputs) correspond to bits 0 to 1
- ONES (fieldbus interface) correspond to bits 6 to 15
Table of hardware conguration codes1
693
697
Upd.F
R Fieldbus software version
695
(oD.F
R Fieldbus node
696
bAu.F
R Fieldbus baudrate
bit Value indicated
by GFX-OP (*)
0 = 1 INPUT AUX absent 0
1 = 1 INPUT AUX TC / 60mV 1
2 -
3 = 1 FIELDBUS ETH4 (ProNET)
4 = 1 FIELDBUS ETH5
5 = 1 FIELDBUS ETH6
6 = 1 FIELDBUS absent O
7 = 1 FIELDBUS Modbus m
8 = 1 FIELDBUS Probus P
9 = 1 FIELDBUS CanOpen C
10 = 1 FIELDBUS DeviceNet d
11 = 1 FIELDBUS Ethernet E
12 = 1 FIELDBUS Euromap66 c
13 = 1 FIELDBUS Eth3 3
14 = 1 FIELDBUS Eth2 (EtherCAT) 2
15 = 1 FIELDBUS Eth1 (Ethernet IP) 1
Profibus
0 12.00 Mbit/s
1 6.00 Mbit/s
2 3.00 Mbit/s
3 1.50 Mbit/s
4 500.00 Kbit/s
5 187.50 Kbit/s
6 93.75 Kbit/s
7 45.45 Kbit/s
8 19.20 Kbit/s
9 9.60 Kbit/s
Canopen
0 1000 Kbit/s
1 800 Kbit/s
2 500 Kbit/s
3 250 Kbit/s
4 125 Kbit/s
5 100 Kbit/s
6 50 Kbit/s
7 20 Kbit/s
8 10 Kbit/s
Devicenet
0 125 Kbit/s
1 250 Kbit/s
2 500 Kbit/s
Ethernet
0 100 Mbit/s
1 10 Mbit/s
