Maximum error of non linearity for thermocouples (Tc), resistance thermometer (PT100)
Type of probe Scale Without dec. point With dec. point
0 TC J °C 0/1000 0.0/999.9
1 TC J °F 32/1832 32.0/999.9
2 TC K °C 0/1300 0.0/999.9
3 TC K °F 32/2372 32.0/999.9
4 TC R °C 0/1750 0.0/999.9
5 TC R °F 32/3182 32.0/999.9
6 TC S °C 0/1750 0.0/999.9
7 TC S °F 32/3182 32.0/999.9
8 TC T °C -200/400 -199.9/400.0
9 TC T °F -328/752 -199.9/752.0
28 TC custom custom custom
29 TC custom custom custom
Tc type:
J, K error < 0.2% f.s.
S, R range 0...1750°C: error < 0.2% f.s. (t > 300°C)
For other ranges: error < 0.5% f.s.
T error < 0.2% f.s. (t > -150°C)
And inserting a custom linearization
E, N, L error <0.2% f.s.
B range 44...1800°C; error < 0.5% f.s. (t > 300°C)
range 44.0...999.9; error f.s.(t>300°C)
U range -200...400; error < 0.2% f.s. (for t > -100°C)
For other ranges; error <0.5% f.s.
G error < 0.2% f.s. (t > 300°C)
D error < 0.2% f.s. (t > 200°C)
C range 0...2300; error < 0.2% f.s.
For other ranges; error < 0.5% f.s.
JPT100 and PT100 error < 0.2% f.s.
The error is calculated as deviation from theoretical value with % reference
to the full-scale value expressed in degrees Celsius (°C).
TC SENSOR
Type of probe Scale Without dec. point With dec. point
30 PT100 °C -200/850 -199.9/850.0
31 PT100 °F -328/1562 -199.9/999.9
32 JPT100 °C -200/600 -199.9/600.0
33 JPT100 °F -328/1112 -199.9/999.9
SENSOR: RTD 3-wires
Type of probe Scale Without dec. point With dec. point
34 0...60 mV Linear -1999/9999 -199.9/999.9
35 0...60 mV Linear Custome linearization Custome linearization
36 12...60 mV Linear -1999/9999 -199.9/999.9
37 12...60 mV Linear Custome linearization Custome linearization
SENSOR: 60mV voltage
Type of probe Scale Without dec. point With dec. point
38 0...20 mA Linear -1999/9999 -199.9/999.9
39 0...20 mA Linear Custome linearization Custome linearization
40 4...20 mA Linear -1999/9999 -199.9/999.9
41 4...20 mA Linear Custome linearization linear. custom
SENSOR: 20mA current
Type of probe Scale Without dec. point With dec. point
42 0...1 V lineare -1999/9999 -199.9/999.9
43 0...1 V lineare linear. custom linear. custom
44 200 mv..1 V lineare -1999/9999 -199.9/999.9
45 200 mv..1 V lineare linear. custom Custome linearization
SENSOR: 1V voltage
Type of probe Scale Without dec. point With dec. point
46 Cust. 20mA - -1999/9999 -199.9/999.9
47 Cust. 20mA - Custome linearization Custome linearization
48 Cust. 60mV - -1999/9999 -199.9/999.9
49 Cust. 60mV - Custome linearization Custome linearization
50 PT100-JPT - custom custom
SENSOR: Custom
400
tYP.
R/W
Probe type, signal, enable, custom
linearization and main input scale
0
Probes and sensors
Table of probes and sensors
99 Input off
403
dP.S
R/W Decimal point position for input scale
0
Format
0 xxxx
1 xxx.x
2 xx.xx (*)
3 x.xxx (*)
(*) Not available for TC, RTD probes
Species the number of decimal gures used to represent the input signal value: for
example, 875.4 (°C) with dP.S = 1.
Decimal point table
Scale limits
401
Lo.S
R/W Minimum scale limit of main input
0
min...max scale
of input selected
in tyP
Engineering value associated to minimum level of the signal generated by the sensor
connected to the input: for example 0 (°C) with type K thermocouple.
402
xi.S
R/W Maximum scale limit of main input
1000
min...max scale
of input selected
in tyP
Engineering value associated to maximum level of the signal generated by the sensor
connected to the input: for example 1300 (°C) with type K thermocouple.
Setting the offset
519
23
ofs.
R/W Offset correction for main input
-999...999
scale points
0
Lets you set a value in scale points that is algebraically added to the value measured by
the input sensor.
Calibrate the UCA inputs by means of the
GFX-OP terminal.
The procedure is described in the GFX-OP
manual.
