Power Fault ALARMS (SSR_SHORT, NO_VOLTAGE, SSR_OPEN and NO_CURRENT)
661
dg.t
R/W
Refresh rate SSR_SHORT
The alarm activates after 3 faults.
1...999 sec
10
662
dg.f
R/W
Time lter for NO_VOLTAGE, SSR_OPEN and NO_CURRENT alarms
Note: set a value not inferior to cycle time.
0...99 sec
10
663
dg.p
R/W
Minimum power for acquisition In.TA and for NO_CURRENT alarm
0.0...100.0%
10,0
660
hd.2
R/W
Enable POWER_FAULT alarms
0
NOTE: the NO_CURRENT alarm setpoint is fixed at 1A
Table of Power Fault alarms
660
hd.2
R/W
Enable POWER_FAULT alarms
0
NOTE: - Activation and state of alarm SSR SHORT is
global for all 4 zones
- the NO_CURRENT alarm setpoint is fixed at 1A
Table of Power Fault alarms
661
dg.t
R/W
Refresh rate In.TA, SSR_SHORT and NO_CURRENT alarms
The alarm activates after 3 faults.
1...999 sec
10
GFX4 with 4 TA
GFX4 with 1 TA
Note: with output power at 100%, NO_VOLTAGE alarm in diagnostic is detected only if an SSR_SHORT-
code is active.
Note related to the parameter dG.t only with 4 CT
* for dG.t < 10 sec. the SSR_SHORT alarm is detected every dG.t seconds only when power = 0%.
* for dG.t ≥ 10 sec. the SSR_SHORT alarm is detected every dG.t seconds switching off the power for
60 msec. indipendently from the power value.
Note: with output power < dG.P the SSR_SHORT alarm in diagnostic is not detected.
SSR_SHORT NO_ VOLTAGE SSR OPEN NO_CURRENT
0
1 X
2 X
3 X X
4 X
5 X X
6 X X
7 X X X
8 X
9 X X
10 X X
11 X X X
12 X X
13 X X X
14 X X X
15 X X X X
+ 32 alarms with memory
SSR_SHORT NO_CURRENT
0
1 X
2
3 X
4
5 X
6
7 X
8 X
9 X X
10 X
11 X X
12 X
13 X X
14 X
15 X X
+ 32 alarms with memory
