gefran GFXTERMO4 User Manual

34
880397M_MSW_GFX4-GFXTERMO4_08-2018_ENG
661
dg.t
R/W
Refresh rate SSR_SHORT
The alarm activates after 3 faults.
1...999 sec
10
662
dg.f
R/W
Time lter for NO_CURRENT alarms
Note: set a value not inferior to cycle time.
0...99 sec
10
660
hd.2
R/W
Enable POWER_FAULT alarms
0
NOTE: the NO_CURRENT alarm setpoint is fixed at 1A
Table of Power Fault alarms
GFXTERMO4 with 4 TA
Read state
93
bit
State of alarm
SSR_OPEN phase 1
R
94
bit
State of alarm
SSR_OPEN phase 2
R
95
bit
State of alarm
SSR_OPEN phase 3
R
96
bit
State of alarm
SSR_SHORT phase 1
R
97
bit
State of alarm
SSR_SHORT phase 2
R
98
bit
State of alarm
SSR_SHORT phase 3
R
99
bit
State of alarm
NO_VOLTAGE phase 1
R
100
bit
State of alarm
NO_VOLTAGE phase 2
R
101
bit
State of alarm
NO_VOLTAGE phase 3
R
102
bit
State of alarm
NO_CURRENT phase 1
R
103
bit
State of alarm
NO_CURRENT phase 2
R
104
bit
State of alarm
NO_CURRENT phase 3
R
105
bit
Reset SSR_OPEN /SSR_
SHORT / NO_VOLTAGE /
NO_CURRENT alarms
R/W
SSR_SHORT NO_CURRENT
0
1 X
2
3 X
4
5 X
6
7 X
8 X
9 X X
10 X
11 X X
12 X
13 X X
14 X
15 X X
+ 32 alarms with memory
