4580397M_MSW_GFX4-GFXTERMO4_08-2018_ENG
152
9
(t.1
R/W
OUT 1 (Heat) cycle time
1 ...200 sec
(0,1 ...20 sec)
2
Set 0 for GTT function
See POWER CONTROL
159
(t.2
R/W
OUT 2 (Cool) cycle time
1 ...200 sec
(0,1 ...20 sec)
20
513
(.ae
R/W
Select cooling uid
0 ...2
0
Relative gain (rG)
0 Air 1
1 Oil 0,8
2 Water 0,4
39
484
c.sp
R/W
Cooling setpoint
relative to heating setpoint
±25.0% f.s.
0,0
78
rst
R/W
Manual reset
(value added to PID input)
-999 ...999
scale points
0
516
p.rs
R/W
Reset power
(value added directly to PID output)
-100,0....
....100,0 %
0,0
79
a.rs
R/W
Antireset
(limits integral action of PID))
0 ...9999
scale points
0
80
ffd
R/W
Feedforward (value added to PID output
after processing)
-100,0....
....100,0 %
0,0
42
146
h.p.x
R/W
Maximum limit
heating power
0.0 ...100,0 %
100,0
254
h.p.L
R/W
Minimum limit heating power
(not available for double heat/cool
action)
0.0 ...100,0 %
0,0
43
c.p.x
R/W
Maximum limit
cooling power
0.0 ...100,0 %
100,0
255
c.p.L
R/W
Minimum limit cooling power (not avail-
able for double heat/cool action)
0.0 ...100,0 %
0,0
2
132 - 471
0v.p
R
Value of control outputs
(+Heat / -Cool)
(W – only in manual mode at address 252)
Read state
The following registers are accessible via serial line:
77
c.dt
R/W
Derivative cooling time
0.00 ...99,99 min
1,00
Note: Parameters c.PB, c.It and c.dt are read-only if heat/cool control is enabled with relative gain (Ctr = 14).
6
c.pb
R/W
Proportional band for cooling or hyster-
esis ON/OFF
0 ...999,9% f.s.
1,0
76
c.1t
R/W
Integral cooling time
0.00 ...99,99 min
4,00
ADVANCED SETTINGS
766
P.oFS
R/W
Offset of output power
765
P..pEr
R/W
Percentage of output power
-100.0 ...100.0 %
0.0
0.0 ...200.0 %
100.0
5
148 - 149
h.pb
R/W
Proportional band for heating or hyster-
esis ON/OFF
0 ...999,9% f.s.
1,0
7
150
h.1t
R/W
Integral heating time
0.00 ...99,99 min
4,00
8
151
h.dt
R/W
Derivative heating time
0.00 ...99,99 min
1,00
