ADV50 QS, SW-PW V1.11 / CTL V2.11 13
Italiano English
Pr. Explanation Settings
Factory
Setting
NOTE
01.40
Mid-Point Frequency
(Fmid) (Motor 3)
0.10 to 600.0 Hz 1.50
115V/230V series: 0.1V to 255.0V 10.0
01.41
Mid-Point Voltage
(Vmid) (Motor 3)
460V series: 0.1V to 510.0V 20.0
01.42
Minimum Output
Frequency (Fmin)
(Motor 3)
0.10 to 600.0 Hz 1.50
115V/230V series: 0.1V to 255.0V 10.0
01.43
Minimum Output
Voltage (Vmin) (Motor
3)
460V series: 0.1V to 510.0V 20.0
Group 2 Operation Method Parameters
a02.00
Source of First
Master Frequency
Command
0: Digital keypad UP/DOWN keys or Multi-
function Inputs UP/DOWN. Last used frequency
saved.
1: 0 to +10V from AVI
2: 4 to 20mA from ACI or 0 to +10V from AVI2
3: RS-485 (RJ-45)/USB communication
4: Digital keypad potentiometer
1
a02.01
Source of First
Operation Command
0: Digital keypad
1: External terminals. Keypad STOP/RESET
enabled.
2: External terminals. Keypad STOP/RESET
disabled.
3: RS-485 (RJ-45)/USB communication. Keypad
STOP/RESET enabled.
4: RS-485 (RJ-45)/USB communication. Keypad
STOP/RESET disabled.
1
02.02 Stop Method
0: STOP: ramp to stop; E.F.: coast to stop
1: STOP: coast to stop; E.F.: coast to stop
2: STOP: ramp to stop; E.F.: ramp to stop
3: STOP: coast to stop; E.F.: ramp to stop
0
02.03
PWM Carrier
Frequency Selections
1 to 15kHz 8
02.04
Motor Direction
Control
0: Enable forward/reverse operation
1: Disable reverse operation
2: Disabled forward operation
0
0: Disable. Operation status is not changed
even if operation command source Pr.02.01 is
changed.
1: Enable. Operation status is not changed even
if operation command source Pr.02.01 is
changed.
2: Disable. Operation status will change if
operation command source Pr.02.01 is
changed.
02.05
Line Start Lockout
3: Enable. Operation status will change if
operation command source Pr.02.01 is
changed.
1
02.06
Loss of ACI Signal (4-
20mA)
0: Decelerate to 0 Hz
1: Coast to stop and display “AErr”
2: Continue operation by last frequency
command
1
