gefran SIEIDrive ADV50 Series

ADV50 QS, SW-PW V1.11 / CTL V2.11 19
Italiano English
Pr. Explanation Settings
Factory
Setting
NOTE
06.02
Over-Current Stall
Prevention during
Operation
0:Disable
20 to 250%
170
06.03
Over-Torque
Detection Mode
(OL2)
0: Disabled
1: Enabled during constant speed operation.
After the over-torque is detected, keep running
until OL1 or OL occurs.
2: Enabled during constant speed operation.
After the over-torque is detected, stop running.
3: Enabled during accel. After the over-torque is
detected, keep running until OL1 or OL occurs.
4: Enabled during accel. After the over-torque is
detected, stop running.
0
a06.04
Over-Torque
Detection Level
10 to 200% 150
06.05
Over-Torque
Detection Time
0.1 to 60.0 sec 0.1
06.06
Electronic Thermal
Overload Relay
Selection
0: Standard motor (self cooled by fan)
1: Special motor (forced external cooling)
2: Disabled
2
06.07
Electronic Thermal
Characteristic
30 to 600 sec 60
06.08 Present Fault Record
06.09
Second Most Recent
Fault Record
0: No fault
1: Over current (oc)
2: Over voltage (ov)
3: IGBT Overheat (oH1)
4: Power Board Overheat (oH2)
5: Overload (oL)
6: Overload1 (oL1)
7: Motor over load (oL2)
8: External fault (EF)
9: Current exceeds 2 times rated current during
accel.(ocA)
10: Current exceeds 2 times rated current during
decel.(ocd)
11: Current exceeds 2 times rated current during
steady state operation (ocn)
06.10
Third Most Recent
Fault Record
06.11
Fourth Most Recent
Fault Record
06.12 Fifth Most Recent
Fault Record
12: Ground fault (GFF)
13: Reserved
14: Phase-Loss (PHL)
15: Reserved
16: Auto Acel/Decel failure (CFA)
17: SW/Password protection (codE)
18: Power Board CPU WRITE failure (cF1.0)
19: Power Board CPU READ failure (cF2.0)
20: CC, OC Hardware protection failure (HPF1)
21: OV Hardware protection failure (HPF2)
22: GFF Hardware protection failure (HPF3)
23: OC Hardware protection failure (HPF4)
24: U-phase error (cF3.0)
25: V-phase error (cF3.1)
26: W-phase error (cF3.2)
27: DCBUS error (cF3.3)
28: IGBT Overheat (cF3.4)
29: Power Board Overheat (cF3.5)
0
