Pr. Explanation Settings
Factory
Setting
NOTE
30: Control Board CPU WRITE failure (cF1.1)
31: Control Board CPU
READ failure (cF2.1)
32: ACI signal error (AErr)
33: Reserved
34: Motor PTC overheat protection (PtC1)
35-39: Reserved
40: Communication time-out error of control
board and power board (CP10)
Group 7 Motor Parameters
a07.00
Motor Rated Current
(Motor 0)
30 %FLA to 120% FLA FLA
a07.01
Motor No-Load
Current (Motor 0)
0%FLA to 99% FLA 0.4*FLA
a07.02
Torque
Compensation (Motor
0)
0.0 to 10.0 0.0
a07.03
Slip Compensation
(Used without PG)
(Motor 0)
0.00 to 10.00 0.00
07.04
Motor Parameters
Auto Tuning
0: Disable
1: Auto tuning R1
2: Auto tuning R1 + no-load test
0
07.05
Motor Line-to-line
Resistance R1 (Motor
0)
0~65535 mΩ 0
07.06
Motor Rated Slip
(Motor 0)
0.00 to 20.00 Hz 3.00
07.07
Slip Compensation
Limit
0 to 250% 200
07.08
Torque
Compensation Time
Constant
0.01 ~10.00 Sec 0.10
07.09
Slip Compensation
Time Constant
0.05 ~10.00 sec 0.20
07.10
Accumulative Motor
Operation Time (Min.)
0 to 1439 Min. 0
07.11
Accumulative Motor
Operation Time (Day)
0 to 65535 Day 0
07.12
Motor PTC Overheat
Protection
0: Disable
1: Enable
0
07.13
Input Debouncing
Time of the PTC
Protection
0~9999(*2ms) 100
07.14
Motor PTC Overheat
Protection Level
0.1~10.0V 2.4
07.15
Motor PTC Overheat
Warning Level
0.1~10.0V 1.2
07.16
Motor PTC Overheat
Reset Delta Level
0.1~5.0V 0.6
07.17
Treatment of the
Motor PTC Overheat
0: Warn and RAMP to stop
1: Warn and COAST to stop
2: Warn and keep running
0
07.18
Motor Rated Current
(Motor 1)
30 %FLA to 120% FLA FLA
07.19
Motor No-Load
Current (Motor 1)
0%FLA to 99% FLA 0,4*FLA
