Gehl 5625 User Manual

SL5625 - CHASSIS, FUEL TANK, GRILLE AND COVERS
PRINTED IN U.S.A.
11
907221/BP0698
SN 8565 AND LATER (H/F), SN 8868 AND LATER (T-BAR)
a) Before SN 9548.
b) SN 9548 and later.
c) SN 9051 and later.
Ref Part Quantity
No. No. Description 5625
32
123661
b
CAP/LOCKING (INCLUDES KEY 080306) 1
096613
b
CAP/NON-LOCKING 1
33 079335 TUBE/RETURN 1
34 079336 TUBE/SUCTION 1
35 121008 FITTING/COMPRESSION 2
36 087852 CLAMP/HOSE 3
37
128621
b
TANK/FUEL 1
38 650517 PLUG/HEX SOCKETHEAD 1/4 PIPE 1
39 087867 GUIDE/TANK LOWER 1
650486 CS 5/16 X 3/4 (NILN) 2
40 087866 SUPPORT/FUEL TANK 1
41 089042 SENDER/FUEL 1
651312 THMS #10-24 X 1/2 5
42 072343 GASKET/FUEL SENDER 1
43
088921
a
TANK/FUEL 1
44
061166
a
CLAMP/HOSE 1
45
079482
a
ADAPTER/TANK 1
46
079483
a
FLANGE/TANK 1
47
079416
a
CAP/LOCKING (INCLUDES KEY 080306) 1
128170
a
CAP/NON-LOCKING 1
48 127311 GRILL/REAR 1
49 088035 PIN/PIVOT 2
650495 CS 1/2 X 1-1/4 (L, P) 2
50 088034 LOCK/COVER 1
650487 CS 5/16 X 1 (NILN) 2
51 R13247 SPRING/COMPRESSION 1
52 088140 PIN/LATCH 2
650706 CS 1/4 X 2 (NILN, 2P) 1
53 088141 ROD/LATCH 1
54 075237 BUSHING/PIVOT 3
55 088139 HANDLE/LATCH 1
650426 CS 1/4 X 1-1/4 (NILN, P) 1
56 062282 GRIP 1
57
128202
c
GUIDE/HOSE RT 1
650687 CB 5/16 X 3/4 (LN, P) 3
58
128192
c
GUIDE/HOSE LT 1
650687 CB 5/16 X 3/4 (LN, P) 3

Gehl 5625 Specifications

General

Brand	Gehl
Model	5625
Category	Compact Loader
Language	English
