SL5625 - CHASSIS, FUEL TANK, GRILLE AND COVERS
PRINTED IN U.S.A.
15
907221/BP0698
BEFORE SN 8868
Ref Part Quantity
No. No. Description 5625
40 087867 GUIDE/TANK LOWER 1
650486 CS 5/16 X 3/4 (NILN) 2
41 087866 SUPPORT/FUEL TANK 1
42 089042 SENDER/FUEL 1
651312 THMS #10-24 X 1/2 5
43 072343 GASKET/FUEL SENDER 1
44 127311 GRILL/REAR 1
45 088035 PIN/PIVOT 2
650495 CS 1/2 X 1-1/4 2
46 088034 LOCK/COVER 1
650487 CS 5/16 X 1 (NILN) 2
47 088140 PIN/LATCH 2
650839 CS 1/4 X 2-1/4 (NILN, 2P) 1
48 088141 ROD/LATCH 1
49 R13247 SPRING/COMPRESSION 1
50 075237 BUSHING/PIVOT 3
51 088139 HANDLE/LATCH 1
650426 CS 1/4 X 1-1/4 (P, NILN) 1
52 062282 GRIP 1
To Next Page
