SL5625 - INSTRUMENT PANEL, WIRING & COMPONENTS
PRINTED IN U.S.A.
23
907221/BP0698
SN 9117 AND LATER
a) For replacement Key, order 089070.
b) SN 9668 and later.
c) For replacement, also order the following:
- One 088150 Light/Horn Decal, item 30
- One 124088 Ignition Switch Decal, item 31
d) SN 9668 and later. The 128920 Switch Assembly includes one 058365 Switch and two 128872 Wire Assemblies.
e) Before SN 9668, order 129044 Kit which includes the following:
- One 128920 Switch Assembly (includes one 058365 Switch and two 128872 Wire Assemblies)
- One 128943 Spacer
- One 128979 Bracket/Pivot RT, see page titled “Restraint Bar”
- One 128984 Bracket/Pivot LT, see page titled “Restraint Bar”
f) For replacement Switch, see pages titled “Standard Lights, Wiring & Components”.
g) SN 10636 and later.
h) Before SN 10636.
j) SN 11242 and later.
k) Before SN 11242.
Ref Part Quantity
No. No. Description 5625
1
127802
c
PANEL/INSTRUMENT 1
650945 THMS 1/4 X 3/4 3
2 124089 GROMMET 1
3
114599
h
COVER/MALE CONNECTOR 1
4 067750 NUT/SPEED 1/4 3
5 072340 HOURMETER 1
651345 RHMS #6-32 X 1/2 (N, L) 2
6 074091 TIE/NYLON 3/16 X 14-1/2 1
7 079196 BUZZER 1
8 072337 GAUGE/FUEL 1
9 072336 GAUGE/WATER TEMP 1
10 088040 HOUSING/DISPLAY 1
651343 RHMS #10-24 X 1/2 (N, L) 2
11 128285 LENS/INSTRUMENT 1
12 071149 FUSE/20 AMP 1
13 069745 HOLDER/20 AMP FUSE 1
14
131050
k
RETAINER/KEY 1
131748
j
RETAINER/KEY 1
15
089069
ak
SWITCH/IGNITION 1
131688
j
SWITCH/IGNITION 1
16 079259 FUSE/30 AMP 1
17 079258 HOLDER/30 AMP FUSE 1
18 087861 HARNESS/GROUND 1
19 128738 BULB/LIGHT TYPE #194 3
20
129928
LENS/GLOW PLUG INDICATOR 1
21 088976 WIRE/IGNITION SWITCH TO FUSE 1
22 651343 RELAY 3
651343 RHMS #10-24 X 1/2 (N, L) 3
23
124039
HARNESS/INSTRUMENT 1
24
REF
f
SWITCH/LIGHT 1
25
128943
b
SPACER/LIMIT SWITCH 1
26
128920
de
SWITCH ASSEMBLY/RESTRAINT BAR 1
651313 RHMS #6-32 X 1-1/2 (N, L, 1P) 2
27 128872 WIRE ASSEMBLY/ LIMIT SWITCH 2
28
080868
h
SWITCH/SEAT 1
130354
g
SWITCH/SEAT 1
29 129929 BULB/LIGHT TYPE #68 1
30 088150 DECAL/LIGHT & HORN 1
31 124088 DECAL/IGNITION SWITCH 1
32 089071 CLAMP/HALF 3
650510 CAP/SCREW 5/16 X 1/2 3
