SL5625 - HYDRAULIC COMPONENTS
PRINTED IN U.S.A.
97
907221/BP0698
TILT CYLINDER
a) Replaced by PN 123444 Tilt Cylinder.
TILT CYLINDER 123444 (3” BORE, 1-1/2” ROD) SN 8585 THROUGH SN 8867
TILT CYLINDER 123932 (2-3/4” BORE, 1-1/2” ROD) SN 8868 AND LATER
Ref Part Quantity
No. No. Description 5625
079241
a
TILT CYLINDER - ASSEMBLY CONSISTS OF: 2
1 080319 NUT/LOCK 3/4-16 UNC 1
2 080318 PISTON 1
3 080320 WELDMENT/TUBE 1
4 080316 GLAND 1
5 080309 HEADCAP/GLAND 1
6 080317 WELDMENT/ROD 1
7 080307 SEAL KIT 1
Ref Part Quantity
No. No. Description 5625
123444
TILT CYLINDER - ASSEMBLY CONSISTS OF: 2
1 080313 NUT/LOCK 1-14 UNC 1
2 080312 PISTON 1
3 080320 WELDMENT/TUBE 1
4 080308 GLAND 1
5 080309 HEADCAP/GLAND 1
6 123424 WELDMENT/ROD 1
7 080307 SEAL KIT 1
Ref Part Quantity
No. No. Description 5625
123932
TILT CYLINDER - ASSEMBLY CONSISTS OF: 2
1 080313 NUT/LOCK 1-14 UNC 1
2 124073 PISTON 1
3 124075 WELDMENT/TUBE 1
4 124072 GLAND 1
5 124074 HEADCAP/GLAND 1
6 123424 WELDMENT/ROD 1
7 124071 SEAL KIT 1
079241 (3” BORE, 1-1/4” ROD)
BEFORE SN 8585
