24 917001/CP0905
Two-Speed Transmission (optional)
Loaders with the optional two-speed transmission have a button on the left con-
trol handle for shifting between High (H) and Low (L). Shifting to High allows
the machine to exceed 8 mph (13 km/h), up to a maximum speed of 12.4 mph
(20 km/h).
Hydraglide™ Ride Control System (optional)
Loaders with the optional ride control feature have a button on the right control
handle for shifting between normal mode and ride control mode. The ride control
system provides a smoother ride over uneven surfaces. Press the button once to acti-
vate the system and again to deactivate. The ride control system is automatically
deactivated when the machine is shut off.
When hydraglide is activated, the lift arm may
drop slightly without a load or several inches
with a heavy load.
Auto-Shutdown System
The auto-shutdown system will activate if the loader has an over-temperature sit-
uation or no oil pressure for more than 30 seconds. An audible alarm will sound
and the Engine Coolant Temperature light or Engine Oil Pressure light will turn
on and the loader will shut down after approximately 30 seconds.
Attachment Mounting
The skid-steer loader is equipped with either the standard manual All-Tach hitch
or the optional Power-A-Tach hitch for mounting a bucket and other attachments.
All-Tach™ Hitch
With the standard hitch mechanism, two
latch levers secure the attachment.
Rotate the levers until the handles are
horizontal to engage the lock pins.
Rotate the levers until the handles are
vertical to disengage the lock pins.
(Refer to page 40 for more information.)
To prevent unexpected release of the attach-
ment from the hitch, be sure to secure the
latch pins by rotating the levers all the way to the stops.
WARNING
Figure 8 All-Tach™ Hitch
WARNING
