917001/CP0905 63
Electrical System
Circuit Breakers
The circuit breakers for the inside electrical system are located on the right
instrument panel.
Battery
Before servicing the battery or electrical
system, be sure the battery disconnect switch
is in the OFF position.
The battery on the loader is a 12-volt, wet cell battery. To access the battery, open
the engine access cover, unlatch and open the rear grille.
The battery top must be kept clean. Clean it with an alkaline solution (ammonia
or baking soda and water). After foaming has stopped, flush the battery top with
clean water. If the terminals and cable connection clamps are corroded or have a
build-up, disconnect the cables and clean the terminals and clamps with the same
alkaline solution.
Explosive gas is produced when a battery is
in use or being charged. Keep flames or
sparks away from the battery area. ALWAYS charge the battery in
a well-ventilated area.
Never lay a metal object on top of a battery, because a short circuit
can result.
Battery acid is harmful on contact with skin or fabrics. If acid spills,
follow these first-aid tips:
1. Immediately remove any clothing on which acid spills.
2. If acid contacts the skin, rinse the affected area with running water
for 10 to 15 minutes.
3. If acid contacts the eyes, flood the eyes with running water for 10
to 15 minutes. See a doctor at once. Never use any medication or
eye drops unless prescribed by the doctor.
4. To neutralize acid spilled on the floor, use one of the following mix-
tures:
a. 1 pound (0.5 kg) of baking soda in 1 gallon (4 L) of water, or
b. 1 pint (0.5 L) of household ammonia in 1 gallon (4 L) of water
Whenever the battery is removed, be sure to disconnect the nega-
tive (-) battery terminal connection first.
WARNING
WARNING
