Upgradeable PDU Instruction Manual44
© 2017 Geist
GM1157
The .csv data output organizes data first by serial number and then by date & time. You can further
organize the data by using the ‘Filter’ option in Excel.
The data structure is split into two sections:
1. PDU configuration data includes:
· Serial Number
· Frame Definition
· Date/Time stamp
· IPv4 address
2. Power Data includes:
· Power Readings
· Totals
Table 3-1 CSV Data
PDU Configuration Data
Serial#
FrameDef
YYYY-MM-DD-HH-MM-SS
IP Add
Products unique
serial number. This is
the same serial
number present on
the units label.
Part of the VLC
configuration data
and used for
debugging.
Timestamp of when the scan
occurred.
The IPv4 address of
the unit. Locally
Metered units will
show Null IP address.
Power Data
1 Volts
1 Amps
1 Watts
1 VA
1 kWh
Input Phase for
Single Phase
units. Phase A or
Phase AB if 3
Phase
Phase Amperes
Phase Real Power
Phase Apparent
Power
Phase Kilowatt-
Hours
2 Volts
2 Amps
2 Watts
2 VA
2 kWh
Phase B or Phase
BC if 3 Phase
Phase Amperes
Phase Real Power
Phase Apparent
Power
Phase Kilowatt-
Hours
3 Volts
3 Amps
3 Watts
3 VA
3 kWh
Phase C or Phase
AC if 3 Phase
Phase Amperes
Phase Real Power
Phase Apparent
Power
Phase Kilowatt-
Hours
