· Indicates the number of Alarms and Warnings currently occurring, if any.
5. Device Label
· Displays the user-assigned label of this unit (see "Configuration and Operation", "Device
Labeling").
6. Device ID
· Unique product identification and cannot be changed. May be required for technical support.
7. Total and Individual Phase Monitor
· Displays AC current, voltage, and power statistics for each individual phase, and for the total of
all phases combined.
8. Current Monitor
· Displays AC current draw statistics for each individual circuit on the PDU.
Figure 3-15 Icons
Configuration Icon Operation Icon
NOTE
You must log in before making any changes. Only users with Control-
level authorizations have access to these settings..
